Single column vertical turning machines

    Payment Type: L/C
    Incoterm: FOB
    Min. Order: 1 Set/Sets
    Delivery Time: 30 Days

Basic Info

Model No.: C5112

Type: Vertical Lathe

Processing Accessory: Chuck CNC Lathe

Guide Rail: Horizontal Guide Rail

Tool Holder: Single-tool Holder CNC Lathe

Power Source: Manual

Controlling Mode: Artificial

Automatic Grade: Manual

Setting Mode: Table

Precision: Normal Precision

Certification: ISO 9001

Condition: New

Table Diameter: 1000mm

Maximum Turning Diameter: 1250mm

Maximum Height Of Workpiece: 1000mm

Maximum Weight Of Workpiece: 3200kg

Additional Info

Packaging: as request

Productivity: 5 set

Brand: Shengyong

Transportation: Ocean

Place of Origin: China

Supply Ability: 5 set /month

Certificate: ISO9001

Port: Tianjin

Product Description

This series of vertical turning machines are single column vertical lathe, there is a vertical knife and a side turret.Vertical turning machines can adapt to high-speed steel cutting tools and carbide cutting tools for processing kinds of ferrous metals, non-ferrous metals and some non-metallic materials.

Vertical turning machines can process cylindrical surface, end face, inner conical surface, outer conical surface, grooving and reaming. Usually,there are two forms of the turret: square ram and manual pentagonal turret.Vertical Turning Lathe operation is easy,electrical control is by PLC.The cast part adopts resign sand for foundry technique to keep high quality. Vertical turning machines can install DRO,side tool post if customers want.Vertical turning lathe sale has a wide range versatility, suitable for machinery manufacturing and fit for parts batch, small batch production.

Single column vertical turning lathe sale

C5112/C5116/C5118/C5120/C5123/C5125/C5126

Maximum turning diameter: 1250/1600/1800/2000/2300/2500mm

Maximum height of workpiece: 1000//1200/1300/1350 mm

Maximum weight of workpiece 3.2 / 5 / 6 / 8 / 10 t

Vertical turning machines


Technical specification of vertical turning lathe sale C5112

1 Table diameter 1000 mm

2 Maximum turning diameter 1250 mm

3 Maximum height of workpiece 1000 mm

4 Maximum weight of workpiece 3.2 t

5 Speed change of table 6.3-200 r/min

6 rotation speed of work table 16 step

7 Feed rates 0.8-86 mm/min

8 Step 12 step

9 Horizontal travel of tool post 700 mm

Vertical travel of tool post 650 mm

10 Horizontal travel of side cutter bar 600 mm

Vertical travel of side cutter bar 800 mm

11 Crossrail travel 500 mm

12 Maximum section scale of tool bar 30×40 mm

13 Power of main motor 22 kw

revolutions 1470 r/min

14 Power of Feed motor 1.3/1.7 kw r/min

Revolutions 940/1440 r/min

15 Machine weight 9.5 t

16 Overall dimensions(L×W×H) 2460×2380×3000 mm
