Types of cnc vertical lathe machinery sales

    Payment Type: L/C
    Incoterm: FOB
    Min. Order: 1 Set/Sets
    Delivery Time: 28 Days

Basic Info

Model No.: CK5125

Type: Vertical Lathe

Processing Accessory: Chuck CNC Lathe

Guide Rail: Horizontal Guide Rail

Tool Holder: Single-tool Holder CNC Lathe

Power Source: Electric

Controlling Mode: CNC

Automatic Grade: Manual

Setting Mode: Table

Precision: Normal Precision

Certification: ISO 9001

Condition: New

Table Diameter: 2300 Mm

Maximum Turning Diameter: 2500 Mm

Maximum Height Of Workpiece: 1350 Mm

Maximum Weight Of Workpiece: 10ton

Additional Info

Packaging: as request

Productivity: 5 set

Brand: hengshui shengyong

Transportation: Ocean

Place of Origin: China

Supply Ability: 5 set /month

Certificate: ISO9001

Product Description

Types of vertical Lathe Machine is a large-scale machinery tools , mainly used to process large and heavy workpieces. The types of lathe machines apply to large radial size but relatively small axial dimensions of the workpiece,such as a variety of discs, wheels and sets the workpiece in the end face, cylindrical surface. In addition, some additional devices can be also used in types of lathe machine,such as threading ,milling and grinding etc processing.

Types of lathe machine

Technical specification types of Cnc Vertical Lathe machinery sales CK5125

1 Table diameter 2300 mm

2 Maximum turning diameter 2500 mm

3 Maximum height of workpiece 1350 mm

4 Maximum weight of workpiece 10 t

5 Speed change of table 2.5-80 r/min

6 Rotation speed of work table 16

7 Feed rates 0-1000 mm/min

8 Step stepless

9 Horizontal travel of tool post 1600 mm

Vertical travel of tool post 915 mm

10 Horizontal travel of side cutter bar 750 mm

Vertical travel of side cutter bar 1100 mm

11 Crossrail travel 850 mm

12 Maximum section scale of tool bar 35×45 mm

13 Power of main motor 45 kw

revolutions 1470r/min

14 Power of Feed motor 1.3/1.7 kw

Revolutions 940/1440 r/min

15 Rapid travelling speed of tool post 2000 mm/min

16 Machine weight 23 t

17 Overall dimensions(L×W×H) 3450×3430×4100 mm

Different types of cnc lathe machinery sales

Types of lathe machinesTypes of lathe machinesTypes of lathe machines

Looking for ideal Types of Lathe Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Types of Lathe Machines are quality guaranteed. We are China Origin Factory of CNC Machinery Sales. If you have any question, please feel free to contact us.
