CNC 5 Axis machining centers

Main characteristic of CNC 5-Axis machining centers

Table adopts constant current hydrostatic guidway with features of high loading capacity,high speed and high accuracy.

Technical parameters of 5-Axis Vertical Machining Center VMC 315

Table diameter 2830 mm

Maximum machining diameter 3150 mm

Maximum machining height 2000/2500 mm

Maximum loading capacity of table 20 T

Table guideway type Hydrostatic

Turning speed of table 160 r/min

Milling speed of table 0.0002-2 r/min

Maximum torque of table 80 KNm

Section size of Ram

Turning 240×240 mm

Milling 320×320 mm

Maximum travel of Ram Z axis 1600 mm

Rapid travel of head (X,Z axis) 2000 mm/min

Maximum cutting force when machining Turning 35 KN

Milling 50 KN

Spindle speed of boring milling 10-2500 r/min

Beam lift speed 360 mm/min

Power of main motor 55 KW
