Metal lathe machine

Product categories of Metal lathe machine, we are specialized manufacturers from China, Metal Lathe Machine, Small Metal Lathe suppliers/factory, wholesale high-quality products of Metal Lathe Tools R & D and manufacturing, we have the perfect after-sales service and technical support. Look forward to your cooperation!
Heavy duty Conventional Vertical Lathe VTL
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
The metal lathe machine has the characteristics of high speed, high torque, high rigidity and so on.Heavy duty VTL is widely used in the automotive industry at home and abroad. Conventional vertical lathe consists of the base, the worktable, the...
China Metal Lathe Machine of with CE
Single column gantry type cnc vtl for sale
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Gantry type cnc vtl lathes have good performance in processing inside and outside cylindrical surface, conical surface, inside and outside the plane, the arc surface of the thread machining. Gantry type cnc vtl lathes are widely used in metallurgy,...
China Manufacturer of Small Metal Lathe
New Single column vtl cnc vertical lathe
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
We continue to innovate new products, improve product performance, This series of CNC VTL cnc vertical turning lathe can simultaneously control the X, Z two-axis movement. CNC VTL cnc vertical turning lathe can be used to process ferrous metals,...
High Quality Metal Lathe Tools China Supplier
vertical lathe machine tool for metalworking
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 3 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
The vertical lathe machine tool is suitable for hard alloy and ceramic cutting tool of ferrous metals, non-ferrous metals and some non-metallic parts.Lathe machine tool is really appropriate for processing inner and outer cylinder, inner and outer...
High Quality Benchtop Metal Lathe China Factory
Processing 2500mm CNC vertical lathe series
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
CK52 series cnc vertical lathe series can be equipped with CNC system in accordance with user requirements, with constant speed cutting function,realizing X axis (horizontal turret movement) Z axis (ram vertical movement) two coordinates to move.The...
China Supplier of Metal Lathe Machine
Single Column CNC Vertical Lathe for metalworking
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
CK51 series machine is single column metal vertical lathe for machining the internal and external cylindrical surface, tapered surface, end face, grooving and chamfering. Single column cnc lathe machine is a muti-purpose metal cutting equipment for...
China Factory of Small Metal Lathe
High quality large cnc lathes for sale
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Cheap vertical turning lathe is mainly used to process all kinds of revolving body surface (inside and outside cylinder surface, taper surface, revolving body forming surface, etc.) and CNC machine tools for sale can process external thread and...
Metal Lathe Tools Made in China
Manual vertical lathe machines for sale
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
This series of cheap vertical turning lathe C5126 belongs to manual lathe machines,cheap vertical turning lathe is mainly used for high-speed steel and carbide cutting tools for a variety of ferrous metals, non-ferrous metals and parts of...
Professional Manufacturer of Benchtop Metal Lathe
Cheap double column economic cnc vertical lathe
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Economic cnc vertical lathe adopts the domestic advanced technology meet the requirements of heavy cutting, high dynamic and static precision, long service life and high processing efficiency,is a cheap cnc vertical lathes.Economy vertical lathe is...
Leading Manufacturer of Metal Lathe Machine
Reliable metal vertical cnc turning lathes machines
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
C52 series vertical cnc lathes machines is a newly developed metal turning lathe. The metal turning lathe machine has the advantages of large load, high machining accuracy, easy operation and wide application. Vertical cnc lathes machines can be...
Professional Supplier of Small Metal Lathe
Vertical cnc metal lathe machine for sale
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Vertical cnc lathe is mainly suitable for high-speed steel cutter and carbide ceramic tool, rough machining of circular arc surface and complex surface, inner and outer cylindrical surface, inner and outer conical surface, thread.The vertical cnc...
How does a vertical lathe work
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
What is a vertical lathe machine ? As we know, vertical lathe belongs to universal lathe machine, applicable to a variety of small and medium circular parts, shell and flange and other parts of the outer circle and the outer conical surface.How does...
Used vertical metal lathe machine CX5232
  • Unit Price: USD 50000 / Set/Sets
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set/month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
This machine is an ordinary double column used vertical lathe machine with two vertical tool post. Used vertical lathe for sale can complete the following processing steps: turning inside and outside cylindrical surface and plane, turning inside and...
Double column cnc type vertical lathe
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set/month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Double column cnc vertical lathe is widely used in the machinery manufacturing and machinery repair and other departments. The double column cnc lathe is well received by the customers because of its convenient operation, safety and reliability and...
Used manual vtl machine for sale
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
CNC vertical lathe machines are suitable for various kinds of ferrous metal, nonferrous metal and some non machining parts made of metal material. CNC vertical lathe machines can be completed turning the outer cylinder surface, inner and outer...
Large double column vertical turret lathe
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Double column vertical turret lathe C5225 is a universal double column vertical lathe, can be used for inner hole and end face, outer circle,inside and outside the cone processing. Vertical turret lathes cnc type and manual type are widely used in...
High Accuracy Vertical Lathe Machine For Turning Flange
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Want to buy cnc vertical lathe for sale? We are vertical lathe trade offer in China. CNC vertical lathe is two coordinate (vertical Z horizontal X) two linkage control vertical CNC lathe. The machine tool has automatic radius compensation, constant...
Vertical turning lathe processing video
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
CNC vertical lathe can be used for turning end face, drilling, outer diameter, cone surface, arc surface, thread, taper thread, end thread, etc. Vertical lathe has wide range and versatility. It is suitable for mechanical manufacture and machining....
Vertical lathe business offer
  • Brand: Shengyong
  • Packaging: as request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
C5112 Vertical lathe machines,maximum turning diameter reach to 1250mm, applicable to the outer cylindrical surface, circular surface dimension and grooving,cutting and fine turning.We are vertical lathe business offer,contact us for vertical lathes...
Recommend cnc vertical lathe machine parts needed
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Vertical lathe machine is suitable for a variety of small ring unit, shell, flanges and other parts of the outer cylinder, circular conical surface and end face turning processing, etc. Vertical lathe has CNC type and manual type. Do you want manual...
Machine lathe machine in stock
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 4 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Vertical lathe machine tools are appropriate for forged iron, steel and nonferrous metal components, rough and end machining with alloy and ceramic cutting tools. For metal metal, nonferrous metal and non-metallic components of the inner and outer...
cnc vertical lathe turning machine cost
  • Brand: Shengyong
  • Packaging: on requet
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
cnc vertical lathe turning machines are suitable for high-speed steel and hard alloy cutter, rough and fine turning processing of inner and outer cylindrical surface, conical surface, plane, all kinds of rotary surface and grooving of ferrous...
Auto feeding cnc vertical lathe machine
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Auto feeding cnc vertical lathe machine Technical specification of Auto feeding cnc vertical lathe machine C5112 1 Table diameter 1000 mm 2 Maximum turning diameter 1250 mm 3 Maximum height of workpiece 1000 mm 4 Maximum weight of workpiece 3.2 t 5...
Vertical turning boring machines
  • Brand: Shengyong
  • Packaging: on request
  • Supply Ability: 5 set /month
  • Min. Order: 1 Set/Sets
  • Certificate: ISO9001
Vertical boring turning lathe machine are suitable for high-speed steel and hard alloy cutter, rough and fine turning processing of inner and outer cylindrical surface, conical surface, plane, all kinds of rotary surface and grooving of ferrous...
China Metal lathe machine Suppliers

Technical specification of Digital readout used metal Vertical Lathe Machine CTX5235

1 Table diameter 2830/ 3150mm
2 Maximum turning diameter of workpiece 3500mm
3 Maximum Height of workpiece 1600/2000/2200/2500/3000mm
4 Maximum Weight of workpiece 10/20T
5 Maximum cutting force of carriage,right tool post 35000N
6 Maximum torque 63000N·m

7 Step of table speed 16 step

8 Speed range of table 2~63rpm
9 Step of feed rate No data
10 Feed range 1~2000mm/min
11 Horizontal travel of tool post 1750mm
12 Vertical travel of tool post 1000mm
13 Rapid traverse speed of crossrail 350mm/min
14 Rapid traverse speed of tool post 2000mm/min
15 Maximum Rotation range of tool post ±30°
16 Travel of Left boring and milling head 600mm
17 Step of Left boring and milling head 8 Step
18 Speed change of Left boring and milling head 66-660r/min
19 Maximum turning diameter of boring hole of Left boring and milling head Ø400mm
20 Size of toolholder clamping((W×H) 40×50mm
21 Power of main motor 55KW
22 Machine weight(appr) 38T
